| Number of heads/stages | 2/2 |
| Max.pumping speed at 50/60 Hz | 1.2 / 1.4 cfm |
| Ultimate vacuum (abs.) | 9 mbar/ 7 torr |
| Ultim. vac. (abs.) with gas ballast | 14 mbar / 11 torr |
| Ambient temperature range (operation) | 10°C – 40°C |
| Max. back pressure (EX) (abs.) | 1.1 bar |
| Inlet connection (IN) | Hose nozzle DN 10 mm |
| Outlet connection (EX) | Hose nozzle DN 10 mm |
| Rated motor power | 0.18 KW |
| Rated speed at 50/60 Hz | 1440 min-1 |
| Dimensions (L x W x H) | 243mm x 243mm x 198mm |
| Weight | 11.1 kg |
| Noise level at 50 Hz, typ. | 45 dBA |
| CE mark | Yes |
| Items supplied | Pump completely mounted, ready for use, with manual |
Performance Features
